OUR GAMES MEET ANDAMIRO'S EXCITING GAMES IN VARIETY!

HOME > GAMES > BASEBALL PRO

TICKET REDEMPTION BASEBALL PRO Grand Slam Collections!

  • 트위터로 보내기
  • 페이스북으로 보내기
  • 구글플러스로 보내기
Dimensions 1,097mm x 2,352mm x 2,812mm
43" x 93" x 111"
Packing Dimensions 1,150mm x 2,280mm x 2,240mm
45" x 90" x 88"
Product Weight 420 kg / 926 lbs
Packing Weight 450 kg / 992 lbs
Power 160W
INQUIRY
PARTS INQUIRY

SUPPORT

  • Leaflets (2)

  • Manuals (1)

  • Document (1)

  • Trouble shooting
    Video List (0)

FEATURES

- MOVING HOME RUN TARGET

- Miniature Baseball Bat Interface

- HIT or OUT TARGETS

- AUTO Mechanical Pitcher

GALLERY

Sorry, this is not available at the moment.

PARTS


동기화 작업중입니다.
페이지를 이동하거나 닫으면 오류가 발생할 수 있습니다.

Total 90Parts

No. Part name Part picture Code Info Part picture Part Add
1

R SIDE LIGHTING LED PCB ASS'Y

BGR

R SIDE LIGHTING LED PCB ASS'Y

ABAP0PCB001

Part picture

2

ELEVATOR SENSOR PCB ASS'Y

2SENSOR

ELEVATOR SENSOR PCB ASS'Y

ABAP0PCB002

Part picture

3

OUT LED PCB ASS'Y

WHITE

OUT LED PCB ASS'Y

ABAP0PCB003

Part picture

4

MOUND LED PCB ASS'Y

BGR

MOUND LED PCB ASS'Y

ABAP0PCB004

Part picture

5

SBO LED PCB ASS'Y

BGR

SBO LED PCB ASS'Y

ABAP0PCB005

Part picture

6

L SIDE LIGHTING LED PCB ASS'Y

BGR

L SIDE LIGHTING LED PCB ASS'Y

ABAP0PCB006

Part picture

7

SPOT LED PCB ASS'Y

WHITE

SPOT LED PCB ASS'Y

ABAP0PCB008

Part picture

8

HR SENSOR PCB ASS'Y

IR_TRANS/RECEIVE

HR SENSOR PCB ASS'Y

ABAP0PCB012

Part picture

9

DROP LED PCB ASS'Y

BGR

DROP LED PCB ASS'Y

ABAP0PCB013

Part picture

10

MOUND CENTER LED PCB ASS'Y

BGR

MOUND CENTER LED PCB ASS'Y

ABAP0PCB014

Part picture

11

PRO ASS'Y

17 PARTS 외2종남광발송

PRO ASS'Y

ABAP0PRO001

Part picture

11.1

[PRO ASS'Y] BAT ROD SHAFT

.

[PRO ASS'Y] BAT ROD SHAFT

MBAP0PRO004

Part picture

11.2

[PRO ASS'Y] WELD-CONTROLLER SHAFT

.

[PRO ASS'Y] WELD-CONTROLLER SHAFT

MBAP0PRO005

Part picture

11.3

[PRO ASS'Y] BAT BUSH

.

[PRO ASS'Y] BAT BUSH

MBAP0PRO001

Part picture

11.4

[PRO ASS'Y] CONTROLLER LOWER HOLDER

.

[PRO ASS'Y] CONTROLLER LOWER HOLDER

MBAP0PRO006

Part picture

11.5

[PRO ASS'Y] BILLBOARD LOGO FIX SHAFT

.

[PRO ASS'Y] BILLBOARD LOGO FIX SHAFT

MBAP0PRO007

Part picture

11.6

[PRO ASS'Y] WELD-CONTROLLER BEARING HOUSING

.

[PRO ASS'Y] WELD-CONTROLLER BEARING HOUSING

MBAP0PRO008

Part picture

11.7

[PRO ASS'Y] CONTROLLER UPPER HOLDER

.

[PRO ASS'Y] CONTROLLER UPPER HOLDER

MBAP0PRO009

Part picture

11.8

[PRO ASS'Y] HR MOVING SHAFT

.

[PRO ASS'Y] HR MOVING SHAFT

MBAP0PRO013

Part picture

11.9

[PRO ASS'Y] WELD-HR ROTATOR

.

[PRO ASS'Y] WELD-HR ROTATOR

MBAP0PRO014

Part picture

11.10

[PRO ASS'Y] ELEVATOR DISK SHAFT

.

[PRO ASS'Y] ELEVATOR DISK SHAFT

MBAP0PRO017

Part picture

11.11

[PRO ASS'Y] ELEVATOR SPACER SHAFT

.

[PRO ASS'Y] ELEVATOR SPACER SHAFT

MBAP0PRO018

Part picture

11.12

[PRO ASS'Y] HR SHAFT BUSHING

.

[PRO ASS'Y] HR SHAFT BUSHING

MBAP0PRO019

Part picture

11.13

[PRO ASS'Y] WELD-BAT BEARING HOUSING

.

[PRO ASS'Y] WELD-BAT BEARING HOUSING

MBAP0PRO022

Part picture

11.14

[PRO ASS'Y] WELD-BAT SHAFT

.

[PRO ASS'Y] WELD-BAT SHAFT

MBAP0PRO024

Part picture

11.15

[PRO ASS'Y] BAT CONNECT SHAFT

.

[PRO ASS'Y] BAT CONNECT SHAFT

MBAP0PRO025

Part picture

11.16

[PRO ASS'Y] BAT

.

[PRO ASS'Y] BAT

MBAP0PRO026

Part picture

11.17

[PRO ASS'Y] CONTROLLER CONNECT SHAFT

.

[PRO ASS'Y] CONTROLLER CONNECT SHAFT

MBAP0PRO027

Part picture

11.18

[PRO ASS'Y] COUPLING

JOC30(D1-8 D2-8)

[PRO ASS'Y] COUPLING

MBAJ0PRO011

Part picture

12

FND PCB ASS'Y

2029-2(STRAIGHT)

FND PCB ASS'Y

AFND0PCB001

Part picture

13

FND PCB ASS'Y

2941-4 (STRAIGHT)

FND PCB ASS'Y

AFND0PCB004

Part picture

14

FND PCB ASS'Y

3856-2(STRAIGHT)

FND PCB ASS'Y

AFND0PCB006

Part picture

15

FND PCB ASS'Y

4870-2 (STRAIGHT)

FND PCB ASS'Y

AFND0PCB008

Part picture

16

FND PCB ASS'Y

90120-4(STRAIGHT)

FND PCB ASS'Y

AFND0PCB024

Part picture

17

DISPLAY COPY PCB ASS'Y

.

DISPLAY COPY PCB ASS'Y

AGST0PCB008

Part picture

18

VOLUME PCB ASS'Y

1 VOLUME

VOLUME PCB ASS'Y

AHM20PCB016

Part picture

19

PHOTO INT-2 PCB ASS'Y

WINNER,WON,CIR공용

PHOTO INT-2 PCB ASS'Y

AWIW0PCB009

Part picture

20

PHOTO INT-1 PCB ASS'Y

ANGLE TYPE

PHOTO INT-1 PCB ASS'Y

AZZZ0PCB103

Part picture

21

SETUP LCD PCB ASS'Y

UNISYSTECH

SETUP LCD PCB ASS'Y

AZZZ0PCB113

Part picture

22

LED BAR 12V ASS'Y

460MM

LED BAR 12V ASS'Y

AZZZ0PCB124

Part picture

23

LED BAR 12V ASS'Y

910MM

LED BAR 12V ASS'Y

AZZZ0PCB128

Part picture

24

BEARING CUSHION MOLD

.

BEARING CUSHION MOLD

MBAP0PLA001

Part picture

25

BAT CUSHION MOLD

.

BAT CUSHION MOLD

MBAP0PLA002

Part picture

26

BEARING CUSHION MOLD-STOPPER

.

BEARING CUSHION MOLD-STOPPER

MBAP0PLA003

Part picture

27

BAT SPRING_4PI

PW 4PI

BAT SPRING_4PI

MBAP0SPR001

Part picture

28

BAT SPRING_3.5PI

PW 3.5PI

BAT SPRING_3.5PI

MBAP0SPR003

Part picture

29

PLUG CUSHION RUBBER

공진 [KD-96R-9] 6MM

PLUG CUSHION RUBBER

MCIR0RUB001

Part picture

30

SPONGE_BALL_GUIDE_CLB

10T, BLACK

SPONGE_BALL_GUIDE_CLB

MCLB0SPO001

Part picture

31

LED STICK BAR BRK

12MM 90도

LED STICK BAR BRK

MELE0000022

Part picture

32

LED STICK BAR BRK

12MM 45도

LED STICK BAR BRK

MELE0000023

Part picture

33

MICRO SWITCH

CNR-05H-03 ZIPPY-FOR COIN

MICRO SWITCH

MELE0MIC002

Part picture

34

NOISE FILTER

ES1-F10

NOISE FILTER

MELE0NOI006

Part picture

35

ROCKER SWITCH

T-125 4P

ROCKER SWITCH

MELE0SWI004

Part picture

36

AC INPUT

DAC-13H

AC INPUT

MELE0SWI015

Part picture

37

TERMINAL BLOCK

KTB1-020 6P UL_CE

TERMINAL BLOCK

MELE0TEB001

Part picture

38

VOLUME KNOB

CAP BLUE

VOLUME KNOB

MELE0VOL007

Part picture

39

BAT

40CM_SILVER

BAT

MZZZ0000577

Part picture

40

BEARING

638ZZ

BEARING

MZZZ0BEA064

Part picture

41

BEARING

F6800ZZ, D10 D19 B5

BEARING

MZZZ0BEA092

Part picture

42

LM BEARING

SL12UU_THC 50*70

LM BEARING

MZZZ0BEA106

Part picture

43

ROD BEARING

JM10_STS304(M10암놈)

ROD BEARING

MZZZ0BEA108

Part picture

44

BALL

BASEBALL PRO_25PI

BALL

MZZZ0BLL003

Part picture

45

CABLE CHAIN

KJP018-1B-R50_25LINK 한쪽끝은 반대

CABLE CHAIN

MZZZ0CBC010

Part picture

46

COUNTER

OA127CL W/2P CONNECTOR_20CM WIRE

COUNTER

MZZZ0COU002

Part picture

47

ROUND BAR PULL

RBP-3-4(KA1232)

ROUND BAR PULL

MZZZ0HAD001

Part picture

48

KEY ONLY 7001

2EA 1SET_WITH RING

KEY ONLY 7001

MZZZ0KEY035

Part picture

49

ORING

AS568A-#204 OD16 D9 3.53PI

ORING

MZZZ0ORI003

Part picture

50

ORING

P3 D2.9 1.9T

ORING

MZZZ0ORI004

Part picture

51

HAND BOLT

M4, PKB4 4*10L

HAND BOLT

MZZZ0PLA030

Part picture

52

GAS SPRING BALL TYPE

GS22*761 15KG

GAS SPRING BALL TYPE

MZZZ0SHO008

Part picture

53

SPEAKER

MID 4.5"+TW1/2" 8Ω

SPEAKER

MZZZ0SPE021

Part picture

54

SPRING

SM12060020 D12 D6 L20

SPRING

MZZZ0SPR032

Part picture

55

AC POWER CORD

250V 16A KKP-4819R CE

AC POWER CORD

MELE0ACP008

Part picture

56

AC POWER CORD UL

125V_10A_SVT 3/18AWG

AC POWER CORD UL

MELE0ACP001

Part picture

57

BP BALL SENSOR PCB ASS'Y

2SENSOR

BP BALL SENSOR PCB ASS'Y

ABAP0PCB015

Part picture

58

MOTOR

KGE-0615-3657-NB1 DC12V 6000RPM

MOTOR

MZZZ0MOT100

Part picture

59

MOTOR

KGE-0308-3657-NB1 DC12V 5000RPM

MOTOR

MZZZ0MOT099

Part picture

60

ATX JOIN 2 OZ PCB ASS'Y

SPONGE BOB PINEAPPLE

ATX JOIN 2 OZ PCB ASS'Y

ASBP0PCB010

Part picture

61

HOLDER ASS'Y

LED포함

HOLDER ASS'Y

MZZZ0BUT103

Part picture

62

FND PCB ASS'Y

2941-3-2C(WCN)(STAIGHT)

FND PCB ASS'Y

AFND0PCB026

Part picture

63

BUTTON SWITCH

AMIPB-60HR-W12D

BUTTON SWITCH

MZZZ0BUT054

Part picture

64

BUTTON SWITCH

TICKET AM1PB-26SH R12D

BUTTON SWITCH

MMUM0BUT002

Part picture

65

COIN BOX ASS WITH 6001

SMALL 200*198*107

COIN BOX ASS WITH 6001

AZZZ0ASS002

Part picture

65.1

[COIN BOX ASS WITH 6001] KEY ASS'Y 6001

6001 키뭉치만

[COIN BOX ASS WITH 6001] KEY ASS'Y 6001

MZZZ0KEY075

Part picture

65.2

[COIN BOX ASS WITH 6001] COIN BOX SMALL

200*198*107 BLACK

[COIN BOX ASS WITH 6001] COIN BOX SMALL

MDRE0PLA007

Part picture

66

COIN SELECTOR

TW-333_WITHOUT FND

COIN SELECTOR

MZZZ0COS045

Part picture

67

TICKET DISPENSER

CLE CL-002Q_270 HIGH SPEED

TICKET DISPENSER

MZZZ0TID010

Part picture

68

BASEBALL PRO IO PCB ASS'Y

WITH CPU

BASEBALL PRO IO PCB ASS'Y

ABAP0ASS005

Part picture

69

COIN BOX ASS WITH C581

SMALL 200*198*107

COIN BOX ASS WITH C581

AZZZ0ASS006

Part picture

70

ATX POWER SUPPLY

FSP300_60GHT_85

ATX POWER SUPPLY

MELE0SMP099

Part picture
